Ascon - ZTT-63GD

Manufacturer Ascon
Part Number ZTT-63GD
Inner Code 4045215
Description DIN rail mount 2 channels input universal transmitter
Custom Code 90329000
Technical specification DIN rail mount 2 channel input universal transmitter ZTT-63GD A no.: G no.: Customs tariff: 9032 9000 2 universal inputs, 2 wires loop powered output - SMART, programmable with USB on the front side - Mathematical functions - Custom linearizations - Linearized inputs for RTDs, thermocouples, mV, potentiometers - RTDs: PT100, PT500, PT1000, Ni100, Ni120, Ni1000, Cu53, Cu100, Cu1000 - Thermocouples: K, J, N, E, T, R, S, L, U, B, C, D, G - Output 4... 20 mA 2 wires - Inputs and output isolated from each other - Loop supply 10... 30 VDC - Burnout, ranges and units of measure (°C -°F) programmable - Programmable with free software (USBSpeedLink) - Instrument supplied by USB port (only for configuration) - DIN rail mounting - Dimensions (W x H x D): 17.5 x 90 x 56.4 mm

Please contact us to request a price quote for Ascon - ZTT-63GD, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Ascon-ZTT-63GD price
