Ascon - XS3100 (unconfigured)
| Manufacturer | Ascon |
|---|---|
| Part Number | XS3100 (unconfigured) |
| Inner Code | 4946408 |
| Description | Digital controller series XS (unconfigured) |
| Custom Code | 90328900 |
| Technical specification | XS series digital controller (unconfigured) Supply voltage: 100... 240V, 50/60 Hz Interface: serial protocol: ASCII Auxiliary output Y4: without Target value: fixed value controller - 1 internal set point and - 4 stored or 1 external setpoint (4-20 mA or 0-10 V) Customs Tariff No.:90321020 Country of origin:Italy inputs: - Pt100, thermocouple (J, L, K, S, R), - standard signal 0 (4)... 20 mA or 0... (1) 10 V - 3 logic inputs or optional - 1 ext. Setpoint input Control output Y1: relay, logic or continuous (4... 20 mA or 0... 10 V) Control behavior: - 2 points (heating or cooling) or - 3 points (heating/cooling, PID, PI, PD, P) Auxiliary output Y2, Y3: alarm relay - configurable as a deviation, band, limit or loop break alarm dimensions: 96*48 mm (DIN), depth 150 mm Protection class: front IP54 Default: - 24 V voltage output for ext. Transmitter - Handheld controller (manual control variable setting) - Auto-tune and expert-tune - CE mark options: - Continuous output (set or actual value, 4... 20 mA or 0... 10 V) - Program controller with (1 program with 11 segments) - IP65 front protection |
Please contact us to request a price quote for Ascon - XS3100 (unconfigured), or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
