Ascon - RP5A30P00B0100S0025P
| Manufacturer | Ascon |
|---|---|
| Part Number | RP5A30P00B0100S0025P |
| Inner Code | 4291083 |
| Description | Straight RTD |
| Technical specification | RP5A30P00B0100S0025P Straight RTD, o. d. from 2 up to 4,5mm, connection wire, optional fixed attaching device. (A) Base A20: EEs-stn 300°C max / 2,0mm Ø G D20: TS 0 200°C max / 2,0mm Ø G G20: Ts t 220°C max / 2,0mm Ø G A30: EEs-stn 300°C max / 3,0mm Ø G D30: TS 0 200°C max / 3,0mm Ø G G30: Ts t 220°C max / 3,0mm Ø G A45: EEs-stn 300°C max / 4,5mm Ø G D45: TS 0 200°C max / 4,5mm Ø G G45: Ts t 220°C max / 4,5mm Ø G (B) Value in Ohm at 0°C P: Pt100 DIN-IEC (C) Element N° and limits 0: 3 wire single el. Cl. B (1 DIN) 1: 3 wire single el. Cl. A (1/2 DIN) 2: 3 wire single el. 1/3 DIN 3: 4 wire single el. Cl. A (1/2 DIN) 4: 4 wire single el. 1/3 DIN 6: 6 wire dual el. CI. B (1 DIN) Ø 4,5 only 7: 6 wire dual el. CI A (1/2 DIN) Ø 4,5 only 8: 6 wire dual el. 1/3 DIN Ø 4,5 only (D) Type of RTD 0: Ceramic 750°C max (E) Sheath material B: AISI 316 (F) Sheath LG mm 0080: 80 mm 0100: 100 mm 0150: 150 mm .... 0450: 450 mm 0500: 500 mm (G) Type of thread S: none A: M6 x 1 - L10 CH-10 ((pour ø2 et ø3) B: M8 x 1.25 - L10 CH - 14 D: M10 x 1.5 - L13 CH - 14 ET: 1/8" Gas - L12 CH - 14 F: 1/4" Gas - L13 CH - 17 M: 1/8" NPT - L10 CH - 14 N: 1/4" NPT - L13 CH - 17 (H) Extension LE 00: none 02: 20 mm 03: 30 mm 05: 50 mm 08: 80 mm (I) Lc wire length 05: 0,5 m 10: 1,0 m ..... 45: 4,5 m 50: 5,0 m 00: 10,0 m (K) Type of termination P: Terminals ø 1.4 - 1.8 max S: Insul. and tinned leads F: Faston 6.35 D: Miniature plug G: Standard plug J: Cylindrical plug ø 17 R: Male ø 12 cylindric plug |
Please contact us to request a price quote for Ascon - RP5A30P00B0100S0025P, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
