Ascon - RF1M60-P00-B0112-F00
| Manufacturer | Ascon |
|---|---|
| Part Number | RF1M60-P00-B0112-F00 |
| Inner Code | 2004157 |
| Technical specification | Replaces type ZTR23M/1P/002200 Low pressure sensors with connection head Series RF1 Straight RTD, 5 to 8 mm sheath o.d., optional fixed attaching device RF1(A)(B)-(C)(D)(E)-(F)(G)-(H)(I) (A) Connection head C: Cylindical IP54 M: Miniature IP67 S: Standard IP67 T: Standard IP67, optional transmitter N: Nylon IP65 Y: Nylon IP65, optional transmitter X: EEx d IIB F: EEx d IIB, IP65, optional transmitter (B) Diameter 50: 5,0 mm 60: 6,0 mm 80: 8,0 mm (C) Value in [ohm] at 0°C P: Pt100 DIN - IEC X: Pt500 DIN - IEC Y: Pt1000 DIN - IEC Z: Ni100 DIN - IEC (D) N° elements / wiring / accuracy 0: 1xRTD, 3-wire, Class B 1: 1xRTD, 3-wire, Class A 2: 1xRTD, 3-wire, 1/3 Class B 3: 1xRTD, 4-wire, 1/3 Class B 4: 1xRTD, 4-wire, 1/3 Class B 5: 2xRTD, 2x2-wire, Class B 6: 2xRTD, 2x3-wire, Class B 7: 2xRTD, 2x3-wire, Class.A 8: 2xRTD, 2x3-wire, 1/3 Class B (E) Type of resistor 0: Ceramic, 750°C max. 1: Thin film, 250°C max. (F) Sheath material B: AISI 316 (1.4541) (G) Sheath length 0080: 80mm (min.) .... 0500: 500mm (max.) (H)Type of thread S: without D: M10 x 1,5 (only for diameter 5+6 mm) E: 1/8" Gas (only for diameter 5+6 mm) F: ¼" Gas H: 3/8" Gas I: 1/2 " Gas M: 1/8" NPT (only for diameter 5+6 mm) N: ¼" NPT P: 3/8" NPT Q: ½ NPT (I) cooling extension length 00: without 05: 50 mm 08: 80 mm 10: 100 mm |
| Weight | 1 |
Please contact us to request a price quote for Ascon - RF1M60-P00-B0112-F00 , or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
