Ascon - M3-5156-0200

Manufacturer Ascon
Part Number M3-5156-0200
Inner Code 4507277
Description Control thermostat series M3 (unconfigured)
Custom Code 90328900
Technical specification Supply voltage: 18... 28 V 48/63 Hz and 20... 30 Vdc output OP1/3: relay (2A/250V normally open) output OP2: relay (2A/250V normally open) or logic (0/5VDC, 30mA) not electrically isolated adjustable via internal jumpers Output OP4: not available Serial interface: RS485 Interface protocol: Modbus/JBus TV+ SE Can be freely configured as follows: input: PT100; thermocouple L, J, T, K, S; 0 (10)... 50 mV DC, 0 (4)... 20mA via shunt OP1/OP3 control or alarm output Output OP2: control or alarm output Control: ON/OFF or PID, heating or cooling, Heating/cooling Assignment: 1 output to control and 2 outputs as alarm 2 outputs for control and 1 output as alarm Options: current transformer input, transmitter supply, Analog output (PV)

Please contact us to request a price quote for Ascon - M3-5156-0200, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Ascon-M3-5156-0200 price

More products of Ascon

  • MS30/099

    Policy

  • MS30/099

    regulator Case dimensions: 48 x 48 mm Power supply: 90 ... 240 VAC

  • MS-30/30 ABA(replaced by MS-32/.9999)

    Configuration 99/99 Power supply 100/240V

  • MS-30/9999/ADM

    (Digital Controls MS (series unconfigured) - Power supply voltage: 100 ... 240V, 50/60 Hz - Serial interface: 2-wire TTY, ASCII optinoal - Dimensions: 48 x 48 mm DIN, depth 110 mm - Weight approx 200 g - input (configurable): * Pt100 * Thermocouple (L, J, K, S) * Standard signal 0 (4) ... 20 mA or 0 ... 1 (10) V Exit: * Main output Y1: relay or logic * Auxiliary output Y2: Alarm relay - PID control with self-optimization and setpoint ramp - heating or cooling characteristic with alarm output or Heating / cooling characteristic without alarm output configurable - Simultaneous display of set and actual values - control output configurable as relays or logic signal - ramp function - Power limitation - scalable inputs for standard signals - configuration via front keys - Voltage output for external 24 V - Transmitter - Parameter lock - Front protection: IP 54, with transparent cover IP 65 (optional) - Customs number: 9032/1020)

  • MS-30/9999/ADM

    (Digital Controls MS (series unconfigured)

  • MS-32/9999

    Digital controller

  • MS-50/9999

    Digitalregler der Serie MS

  • PT100

    Temp. resistence detector ZTR-23M/1P.

  • QF-3000

    universal controller series QF

  • QF-5000/0

    Ascon controller series Gamma 1 Type QF-5000/0 Housing dimensions 96x96 mm Single loop Power supply 24 V AC / DC

  • RB1A60P00B0035F015P

    (Thermo resistance EEs-STN 300°C max D. 6 mm Pt100 DIN-IEC 1 EL.3 wires CI.B (1DIN) CERAMIC 750°C max. G.AISI 316 L.35mm 1/4 GAS-L12 (CH-17) spring length 180mm cable 1,5MT split leads)

  • RQ1S45P80B3000S00

    Temperature probe IP67 D 4,5 mm Pt100DIN-IEC 2 EL. A 6 wires (1/3 DIN) Ceramic 750 C max G.AISI 316 L3000mm NO thread NO ext

  • SCH AC ALI 3

    (Power supply card 85/264V -50/60HZ)

  • SEDA3002SE4

    ROTARY ELECTRIC ACTUATOR

  • SER 20/60024/52 E0000V9

    Nm 20/ sec 60/ 90 degree/ -10+50 degree 24 V/ VA 7

  • TLK48LCR

    Controller. series TLK48 TLK48 type-A-B-C-D-E A: Power supply L-24 V AC / DC H-100 .... 240 V AC B: Input C thermocouple, PT100, mV E thermocouple, NTC, PTC, mV I-0/4 ... 20 mA V-0/1 ... 5 V, 10 V 0/2 ... C: Output 1 R relay O logic signal (SSR) D: output 2 R relay O logic signal (SSR) - - not used E: output 3 R relay O logic signal (SSR) - - not used General data -48x48 mm Front size for panel mounting - protection front IP65 with sealing -Serial communication via TTL interface

  • TLY26-S-

    Digital controller for refrigerating units

  • TLY27-HRR-D02

    defrost controller

  • X1-3100-0200

    Temperature controllers X1 (unconfigured) A.Nr .: G.Nr .: Front: Supply voltage: 100 ... 240 V, 50/60 Hz Ausqanqe: 3 relay (2 Schliefser, 1 PDT) and 1 logic output Serial interface: no Interface protocol: no Actual value OP4: no Operating Instructions: German Front color: dark gray Input: * PT100; Thermocouple I, J, T, K, S, B, N, R, W, Special; 0 (10) .. 50 mV DC * Current transformer input for the Lastkreisuberwachung Control: 10 ... 100A (sec 50/100 mAl. PID, heating 1 Kuhlen,

  • X331000000

    digital process controller
