Ascon - M3-5106-0020

Manufacturer Ascon
Part Number M3-5106-0020
Inner Code 4585142
Description Control thermostat
Technical specification thermostat series M3, M3-5106-0200/9999 (unconfigured) Supply voltage: 18... 28 V 48/63 Hz and 20... 30 Vdc output OP1/3: relay (2A/250V normally open) output OP2: relay (2A/250V normally open) or logic (0/5VDC, 30mA) not electrically isolated adjustable via internal jumpers Output OP4: not available Serial interface: none Interface protocol: without Can be freely configured as follows: input: PT100; thermocouple L, J, T, K, S; 0 (10)... 50 mV DC, 0 (4)... 20mA via shunt OP1/OP3 control or alarm output Output OP2: control or alarm output Control: ON/OFF or PID, heating or cooling, Heating/cooling Assignment: 1 output to control and 2 outputs as alarm O. 2 outputs for control and 1 output as alarm Special features: with integrated transmitter supply Options: current transformer input, transmitter supply, Analog output (PV), serial interface

Please contact us to request a price quote for Ascon - M3-5106-0020, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Ascon-M3-5106-0020 price
