Ascon - M3-3100-0200 (M3-3100-0200/9999)

Manufacturer Ascon
Part Number M3-3100-0200 (M3-3100-0200/9999)
Inner Code 339615
Description temperature controller
Custom Code 90328900
Technical specification M3-3100-0200 M3 series temperature controller (unconfigured) G.No.: A.No.: Customs Tariff No.:90328900 Country of origin:Italy supply voltage: 85... 265 V~ Output OP1/3: relay (2A/250V closer) Output OP2: relay (2A/250V closer) or logic (0/5VDC, 30mA) not galvanically isolated adjustable via internal jumpers Output OP4: none Serial port: none Interface protocol: none Transmitter supply: none Target value/special function: none User manual: German/English Front color: dark gray Can be freely configured as follows: input: PT100; thermocouple L, J, T, K, S; 0 (10)... 50 mV DC, 0 (4)... 20mA via shunt Output OP1: control or alarm output Output OP2: control or alarm output Output OP3: alarm output Output OP4: actual value or setpoint output (option) Control: ON/OFF or PID, heating or cooling Assignment: 1 output to control and 1 output as alarm o. both outputs as an alarm Options: power converter input, transmitter supply, Analog output (PV)
Weight 1

Please contact us to request a price quote for Ascon - M3-3100-0200 (M3-3100-0200/9999), or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Ascon-M3-3100-0200 (M3-3100-0200/9999) price
