ARI - Figur 12.440 DN 25
| Manufacturer | ARI |
|---|---|
| Part Number | Figur 12.440 DN 25 |
| Inner Code | 3291586 |
| Description | flanged flat check valve |
| Technical specification | SN: 1301073555 ARI-STEVI 440 Straight through control valve with flanges EN-JL1040 DN 25 Datasheet:440001-1.pdf Operating instructions:0040301000-1.pdf Nominal pressure: PN 16 Flange drilling: according to DIN PN16 Kvs value: 10 characteristic curve: linear Spindle sealing: roof collars/PTFE graphite Engine: PREMIO Valve lift: 20mm stroke Drive type: PREMIO 2.2kN max. closing pressure (bar): 16 Motor type: BLDC motor Voltage: 90-264V AC 47-63Hz Adjusting speed: 0.38mm/sec Operating time: 53s Spindle overhang: 83mm Coupling: M10 thread |
| Weight | 10 |
Please contact us to request a price quote for ARI - Figur 12.440 DN 25, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
