ARI - 100283505-016
| Manufacturer | ARI |
|---|---|
| Part Number | 100283505-016 |
| Inner Code | 4519589 |
| Technical specification | Figure 23.470 DN 25 ARI-STEVI 470/422 Straight-through control valve with flanges and stem-guided cone EN-JS1049 DN 25 Nominal pressure: PN 16 Flange drilling: according to DIN PN16 Cone design: parabolic cone+PTFE soft seal. up to max. 200°C Kvs value: 10 Characteristic curve: equal percent Spindle sealing: roof sleeves/PTFE graphite Final acceptance test: APZ EN10204 3.1 Acceptance material testing: APZ EN10204 3.1 Drive: DP32 Supplementary product description: * DVGW-tyg-tested according to EN 13611 Additional test requirement: DIN 12266-1, leak rate A Nitrogen test medium however, 10 bar Effectively (b.pneum.antr): Spring closes in case of air failure feathery. (bar) /stroke (mm): 0.80-2.40 stroke 20 mm Erford. Setting pressure (bar): 2.7 bar max. admissible Setting pressure (bar): 6 max. closing pressure (bar): 16 Distance column length: L1=188 mm Distance column spacing: 100 mm Coupling: M10 thread Positioner: EPS 33 Input signal: 4 - 20mA 2-wire Adjusted: 4 mA valve closed Inlet with ventilation air (bar): 6 bar |
Please contact us to request a price quote for ARI - 100283505-016, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
