ARI - ARI-STEVI 405 / Figure 12.405 DN 150
| Manufacturer | ARI |
|---|---|
| Part Number | ARI-STEVI 405 / Figure 12.405 DN 150 |
| Inner Code | 5034136 |
| Technical specification | Figure 12.405 DN 150 ARI-STEVI 405 Straight-through shut-off valve with flanges EN-JL1040 DN150 Datasheet:405001-1.pdf Operating instructions:0040304000-1.pdf Discount group: I51 Nominal pressure: PN 16 Flange drilling: according to DIN PN16 Spindle sealing: roof collars/PTFE graphite Drive: DP34 Wirkw. (b.pneum.ANTR): Spring opens in case of air failure featherwork. (bar) /stroke (mm): 0.20-0.80 stroke 38 mm Erford. Operating pressure (bar): 3.5 bar max. allowable Operating pressure (bar): 5.5 max. closing pressure (bar): 9.2 Distance column length: L1=228mm Distance between columns: 100mm Coupling: M16x1.5 thread |
Please contact us to request a price quote for ARI - ARI-STEVI 405 / Figure 12.405 DN 150, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
