Apollo - 83B-244-24
| Manufacturer | Apollo |
|---|---|
| Part Number | 83B-244-24 |
| Inner Code | 4013365 |
| Technical specification | Description: VALVE_BALL, TYPE: FLOATING, SIZE: 3/4 IN, PRESSURE RATING: CL600, END CONNECTION: SW, PORT: FULL, BODY STYLE: 3-PIECE, BODY MATERIAL: ASTM A216 GR.WCB, BALL MATERIAL: ASTM A276 GR.316, STEM MATERIAL: ASTM A276 GR.316, SEAT MATERIAL: MULTI-SEAL, GASKET MATERIAL: GRAPHITE (FIRE SAFE), PACKING MATERIAL: PTFE (FIRE SAFE), BOLT/NUT MATERIAL: ASTM A193 GR.B8M3/A194 GR.8, OPERATED: HAND LEVER, FACE TO FACE LENGTH: 93.5 MM, DESIGN STANDARD: ASME B16.34, END CONNECTION STANDARD: ASME B16.11, VALVE TESTING STANDARD: API 598, NACE REQUIREMENT: MR-01-75, ANTI STATIC: YES, FIRE SAFE REQUIREMENT: API 607, MATERIAL TEST CERTIFICATE: EN 10204-3.1, MANUFACTURING DATA RECORD: VENDOR TO PROVIDE, SERVICE: SOUR HYDROCARBON, PIPING CLASS/LINE CLASS: BCA, IDENTIFICATION NUMBER: FBAA5, ADDITIONAL FEATURES: SEAL MATERIAL: RESILIENT TYPE GLAND MATERIAL: ASTM A276 GR.316 SPRING MATERIAL: ALLOY X-750 STEM DESIGN: ANTI BLOW-OUT, ONE PIECE BOTTOM ENTRY TEMPERATURE SERVICE: 149 DEG. C AT 17.9 BAR |
Please contact us to request a price quote for Apollo - 83B-244-24, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
