Angst-Pfister - 12.2036.3083
| Manufacturer | Angst-Pfister |
|---|---|
| Part Number | 12.2036.3083 |
| Inner Code | 1802046 |
| Description | stop buffer |
| Technical specification | Material elastomer part:NR, black Material connecting piece:S235JR Form:F Surface treatment:zinc-plated, chromated (CR VI free) Version:DIN 95364, Type F medium Hardness:approx. 55 Shore A Note to hardness: Note to hardness:Spring rates have priority. Note:these stop buffers are also available in hardnesses approx. 40 Shore A (soft) and approx. 70 Shore A (hard). On request:soft hardness, approx. 40 Shore A: spring constant: x 0.5; compressive force: x 0.68 hard hardness, approx. 70 Shore A: spring constant: x 2.0; compressive force: x 1.4 Tolerance:DIN 2768-c; DIN ISO 3302-1 M3; DIN ISO 4759-1 Class A Working temperature:from -30 to +80 °C EU guidelines:2002/95/EC (RoHS) |
| Weight | 0.02 |
Please contact us to request a price quote for Angst-Pfister - 12.2036.3083, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
