Angst-Pfister - 11.6574.0045
| Manufacturer | Angst-Pfister |
|---|---|
| Part Number | 11.6574.0045 |
| Inner Code | 3410081 |
| Description | Wiper Seal BWA 10.00 x 14.00 x 2.80/3.20 mm TPU |
| Technical specification | Rod Ø 10.00 f9 Ground of the groove Ø 14.00 H10 Groove width 3.20 0/+0.2 Ø D1 11.40 0/+0.2 Seal height 2.80 Chamfer 2.5 Material sealing element:TPU 90.447-01 Hardness:90 ±5 Shore A Working temperature:from -30 to +90 °C Medium stability:For use in processed, dried, or de-oiled compressed air Pressure:max. 2 MPa Sliding speed:max. 1 m/s Product description:Pneumatic combination seal, combining a grooved ring and scraper in a single element Application:Single-acting rod seal with good seal tightness and low friction |
| Weight | 0.005 |
Please contact us to request a price quote for Angst-Pfister - 11.6574.0045, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
