Anderson-Negele - FMI-C/ODT/1"/TC/X/DC/X
| Manufacturer | Anderson-Negele |
|---|---|
| Part Number | FMI-C/ODT/1"/TC/X/DC/X |
| Inner Code | 4588856 |
| Description | Magnetic-inductive flow meter |
| Custom Code | 90261021 |
| Technical specification | Materials 78418.7005000 Compact design, electronics housing can be rotated 360° Illuminated on-site graphic display, 4 x 90° rotatable Operation without opening the case using touch keys Mechanical connection: Measuring pipe: DN25 Process connection: Aseptic flange DIN 11864/2 form A Tube standard: OD tube (ASME-BPE), 1" Process connection: Tri-clamp (ASME-BPE, 1") Materiale: Process connection: 1.4404, Ra<=0.8 μm Measuring tube lining: PFA, vacuum-resistant Front-flush electrodes made of 1.4404 Power supply: 9... 32 VDC Electrical connection: cable gland M16x1.5 Inputs/outputs: Analog output: (0) /4... 20 mA, active or passive Pulse output: 2x optocouplers 24 V/20 mA Status output: 1x optocoupler Alternative to IZMAG 025 D000SA00000 |
Please contact us to request a price quote for Anderson-Negele - FMI-C/ODT/1"/TC/X/DC/X, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
