Alerton - AXM-10-12-0
| Manufacturer | Alerton |
|---|---|
| Part Number | AXM-10-12-0 |
| Inner Code | 4750775 |
| Description | Expansion Module for the ACM |
| Technical specification | Expansion Module for the ACM Power - Unit requires 24 VAC, 50- 60Hz, 20VA minimum Half-wave rectified. Output Loads powered separately. 10 inputs - Jumper-selectable, 12- Accept bit universal inputs thermistor, dry contact, 0-5VDC, 4-20mA, or 0-10VDC Signals. Inputs 1, 2, and 3 support Pulsed inputs with 10 msec minimum pulse length. No External resistor is required for 4- 20mA 12 Binary Outputs - Binary Outputs rated 24 VAC @ 0.5 A with Hand-Off Auto (H-O-A) Switches for manual override. H-OA status can be monitored in software. Power Source isolated from AXM power. Max Dimensions - 6.95” (176.5 mm) H X 4.95” (125.7 mm) W X 1.6” (40.5 mm) D Terminations - Removable Header-type screw terminals simplify field wiring Environmental - 32-131°F (0-55° C). 0-95% RH, non-condensing Communications - twisted pair, multi-drop AXM Communications Bus do ACM base unit. |
Please contact us to request a price quote for Alerton - AXM-10-12-0, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
