Airtec - KF-46-510-HN-S12

Manufacturer Airtec
Part Number KF-46-510-HN-S12
Inner Code 3785571
Description Solenoid valve for RE46, 5/2-way with air spring return (monostable)
Custom Code 84812090
Technical specification materials: Body: aluminium/ plastic, seals: NBR temperature range: -10 to +50 °C operating pressure: 3 - 8 bar (0 - 8 bar with external air connection) media: oiled and unoiled, filtered compressed air flow rate: 3/2-way: NC: 430 l/min, NO: 630 l/min, 5/2-way: air spring: 950 l/min, mechanical spring: 810 l/min, pulse valve: 950 l/min, 5/3-way: 680 l/min Control voltages: 24 V DC Voltage tolerance: ± 10% power consumption: 1,3 W/valve solenoid Protection class: IP 65
Weight 0.158

Please contact us to request a price quote for Airtec - KF-46-510-HN-S12, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
