Aerzen - GMb 16.13 HV (786000204)
| Manufacturer | Aerzen |
|---|---|
| Part Number | GMb 16.13 HV (786000204) |
| Inner Code | 3351288 |
| Description | high vacuum blower |
| Custom Code | 84141025 |
| Technical specification | Arrangement: 10 (level), HV Blower housing: material: EN-GJS-400-15 (standard), suitable for air, sealing ring housing: air-cooled (standard), without internal bypass valve Rotors/ Shaft: Material: EN-GJL-200 (standard)/C45+N (standard) Control gears: Material: 16 Mn Cr5 helically toothed, hardened and sanded Fastening using a conical press bandage Storage: roller bearing Lubrication: oil dip lubrication Sealing of the pumping chamber: with four rectangular ring labyrinth seals and injection rings sealing the drive shaft and O-rings housing flange: VITON Conveying direction: from bottom to top Direction of rotation: from right to left When looking at the drive pin Coating: standard primer (RAL 7032) RAL 5001 top coat Drive type: directly via flexible coupling Nominal suction nozzle size: DN 300 in accordance with EN 1092-2, PN 10, drilled Nominal diameter pressure socket: DN 300 in accordance with EN 1092-2, PN 10, drilled |
| Weight | 1160 |
Please contact us to request a price quote for Aerzen - GMb 16.13 HV (786000204), or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
